Photo #: 80-G-172527
Camouflage Measure 31, Design 23D
Drawing prepared by the Bureau of Ships for a camouflage scheme intended for destroyers of the DD-364 (Mahan) class.
This plan, approved by Captain Torvald A. Solberg, USN, is dated 13 April 1944. It shows the vessel's starboard side, superstructure ends, and exposed decks.
Official U.S. Navy Photograph, now in the collections of the National Archives.
Online Image: 124KB; 1200 x 520 pixels
Reproductions of this image may also be available through the National Archives photographic reproduction system.
Click on the small photograph to prompt a larger view of the same image.
If you want higher resolution reproductions than this digital image, see: "How to Obtain Photographic Reproductions."
Image posted 13 November 2005
