Photo #: 80-G-109624 Camouflage Measure 32, Design 3D Drawing prepared by the Bureau of Ships for a camouflage scheme intended for destroyers of the DD-692 (Allen M. Sumner) class. This plan, showing the ship's starboard side, superstructure ends and exposed decks, is dated 29 February 1944, was approved by Captain Logan McKee, USN. Official U.S. Navy Photograph, now in the collections of the National Archives. Online Image: 130KB; 1200 x 695 pixels Reproductions of this image may also be available through the National Archives photographic reproduction system. |
![]() |
Click on the small photograph to prompt a larger view of the same image.
If you want higher resolution reproductions than this digital image, see: "How to Obtain Photographic Reproductions."
Image posted 19 August 2005
