Photo #: 80-G-109635
Camouflage Measure 31, Design 23D
Drawing prepared by the Bureau of Ships for a camouflage scheme intended for destroyers of the DD-372 (Cassin) class.
This plan, showing the ship's starboard side, superstructure ends and exposed decks, is dated 18 May 1944 and was approved by Commander William C. Latrobe, USN.
Official U.S. Navy Photograph, now in the collections of the National Archives.
Online Image: 100KB; 1200 x 640 pixels
Reproductions of this image may also be available through the National Archives photographic reproduction system.
Click on the small photograph to prompt a larger view of the same image.
If you want higher resolution reproductions than this digital image, see: "How to Obtain Photographic Reproductions."
Image posted 20 August 2005
