Photo #: 80-G-166239 Camouflage Measure 31, Design 3D Drawing prepared by the Bureau of Ships for a camouflage scheme intended for gunboats of the PG-50 class. This plan, approved by Captain Logan McKee, USN, is dated 25 February 1944. It shows the ship's port side and superstructure ends. USS Charleston (PG-51) wore this camouflage design. Official U.S. Navy Photograph, now in the collections of the National Archives. Online Image: 115KB; 1200 x 535 pixels Reproductions of this image may also be available through the National Archives photographic reproduction system. |
![]() |
