Photo #: 80-G-173270

Camouflage Measure 33, Design 1A


Drawing prepared by the Bureau of Ships for a camouflage scheme prepared for the aircraft carrier USS Ranger (CV-4), which was later painted in this pattern.
This plan, approved by Captain Torvald A. Solberg, USN, is dated 5 June 1944. It shows the ship's port and starboard sides, and her superstructure ends.
Note that the drawing's darkest color is Navy Blue (5-N), not the Dull Black (BK) specified in the color table.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 201KB; 1500 x 990 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.



Click on the small photograph to prompt a larger view of the same image.

If you want higher resolution reproductions than this digital image, see: "How to Obtain Photographic Reproductions."
