Photo #: NH 69060

"Plan of Berth Deck, &c. -- Tippecanoe Class"


Left half of a construction plan for Tippecanoe (Canonicus) class monitors, circa 1862. These drawings show the ship's berth deck and inboard profile from the boiler room to the bow, plus a cross section of the hull.
See Photo # NH 69061 for the right half of this plan. Scale of the original drawing was 1/4"=1'.

Copied from plan # 7-9-9 in Record Group 19, National Archives.

U.S. Naval Historical Center Photograph.

Online Image: 175KB; 855 x 925 pixels
