USS Kearsarge (BB-5)

and
USS Kentucky (BB-6)

Outboard profile plan, October 1899, showing the ships as built. It includes a wave profile based on trials of Kearsarge at a speed of 17.3 knots.

The original plan is in Record Group 45, U.S. National Archives.

U.S. Naval Historical Center Photograph.

Online Image: 66KB; 740 x 395 pixels
