Photo #: NH 96670

USS Dictator
(1864-1883)

Engraved plan of the ship's transverse section amidships, through the center of her gun turret.
Published in "The Artizan", 1 October 1867.
Note the XV" Dahlgren smoothbore gun in the turret, turret training gears, and the laminated iron armor on Dictator's hull, turret and conning tower.

Courtesy of the Navy Department Library, 1990.

U.S. Naval Historical Center Photograph.

Online Image: 113KB; 740 x 605 pixels
