Photo #: NH 105035

Boat Anchor


Figure 27 (page 152) of "The Naval Artificer's Manual", compiled and arranged by Assistant Naval Constructor (T) McCall Pate, USN, 1918. This figure shows the configuration of standard U.S. Navy boat anchors, with a key to their dimensions.
See Photo # NH 105034 for the text, with a table of referenced dimensions, that accompanied this drawing.

U.S. Naval Historical Center Photograph.

Online Image: 163KB; 740 x 1225 pixels
