Photo #: 19-N-104907

Camouflage Measure 33a, Design 27D


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for destroyers of the Allen M. Sumner (DD-692) class.
This plan, approved by Captain Torvald A. Solberg, USN, is dated 25 October 1944. It shows the ship's port side and one of her midships superstructure ends.

Photograph from the Bureau of Ships Collection in the U.S. National Archives.

Online Image: 136KB; 1200 x 750 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
