Photo #: 19-N-104914

Camouflage Measure 32, Design 3D(ex)


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for escort ships of the Evarts (DE-5) class.
This plan, approved by Captain Torvald A. Solberg, USN, is dated 1 September 1944. It shows the ship's starboard side, horizontal surfaces and superstructure ends. The port side was painted in the lighter tones of Measure 33.

Photograph from the Bureau of Ships Collection in the U.S. National Archives.

Online Image: 191KB; 1200 x 645 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
