Photo #: 19-N-68070

USS Drayton
(DD-366)

Plan view, amidships, taken from a crane at the Mare Island Navy Yard, California, 26 June 1944.
Note quadruple torpedo tube mounts, smokestacks, and non-skid deck tread.
White outlines mark recent alterations to the ship, including twin 40mm gun mounts and their directors.

Photograph from the Bureau of Ships Collection in the U.S. National Archives.
