Photo #: 19-N-73625
Camouflage Measure 32, Design 18F
Drawing prepared by the Bureau of Ships for a camouflage scheme intended for the ammunition ships of the AE-1 class.
This plan, approved by Commander Wallace S. Newton, USN, is dated 17 October 1944. It shows the ship's starboard side, horizontal surfaces and superstructure ends.
Photograph from the Bureau of Ships Collection in the U.S. National Archives.
Online Image: 99KB; 1200 x 705 pixels
Reproductions of this image may also be available through the National Archives photographic reproduction system.
