Photo #: 19-N-73639

Camouflage Measure 31, Design 20L


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for application to the service craft YAG-33 (formerly U.S. Navy PYc-33 and civilian steamer Palace).
This plan, approved by Captain Torvald A. Solberg, USN, is dated 29 August 1944, nearly three months after YAG-33 was stricken and only eleven days before she was sunk as a target. It shows the ship's starboard side, exposed decks and the superstructure ends.

Photograph from the Bureau of Ships Collection in the U.S. National Archives.

Online Image: 144KB; 1200 x 810 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
