Photo #: S-584-063

Preliminary Design No.126 for a Scout Cruiser ... April 26, 1915


Preliminary design plan for a large scout cruiser, prepared to support General Board discussions concerning the characteristics sought in future cruisers.
This plan provided four 14-inch guns and seven 5-inch guns and a speed of 35 knots in a ship 800 feet long on the load water line, 85 feet in beam, with a normal displacement of 25,000 tons. This design included 2,330 tons of armor, 8-inch side armor over 374 feet by 17 feet 6 inches amidships plus 1.5-inch deck protection, adding 14,500 tons displacement over design No.112. This design was last in a set of 11 undertaken as a group during 21 to 29 April 1915 to explore tradeoffs among armament, protection, and size in large scout cruisers capable of 35 knots speed. This design series took Preliminary Design No.112 (see Photo # S-584-050) as a baseline. Ultimately, however, no ships of this type were built.
Note: The original document was a blueprint (white on blue).

The original plan is in the 1911-1925 "Spring Styles Book".

U.S. Naval Historical Center Photograph.

Online Image: 220KB; 1600 x 1075 pixels
