Photo #: S-584-078

Preliminary Design Plan for a Battle Cruiser ... June 1915


Preliminary design plan for a battle cruiser prepared for Captain John Hood of the General Board, apparently requested informally as part of the Board’s wide-ranging review of possible cruiser type ships that was underway at the time. This design may have represented an attempt to design a smaller ship than that developed in May for Captain Hood (see Photo # S-584-072) but neither plan resulted in a design slected for construction.
This plan provides eight 16-inch and twenty 6-inch guns, turbine machinery, and a speed of 30 knots in a ship 1000 feet long, 98 feet. in beam, with a normal displacement of 52,000 tons.
Note: The original document was ink on linen (black on white).

The original plan is in the 1911-1925 "Spring Styles Book".

U.S. Naval Historical Center Photograph.

Online Image: 259KB; 1600 x 1090 pixels
