Photo #: S-584-089

Preliminary Design Plan for a "Battle Scout" ... September 1915


Preliminary design plan for a large scout cruiser, called a "Battle Scout", prepared for the General Board. These "Battle Scout" designs apparently were intended to explore what capabilities might be provided in a large ship type having fewer heavy guns than a Battle Cruiser but having a significantly heavier main battery than the typically lightly armed Scout Cruisers studied earlier in 1915. No "Battle Scouts" were built.
This plan provides eight 14-inch and twelve 6-inch guns, and a speed of 35 knots in a ship 800 feet long on the water line, 94 feet in beam, with a normal displacement of 32,000 tons. Note the provision of side armor in way of the turrets. This additional side protection distinguishes this design from P.D. 144 (see Photo # S-584-083).
Note: The original document was a blueprint (white on dark blue).

The original plan is in the 1911-1925 "Spring Styles Book".

U.S. Naval Historical Center Photograph.

Online Image: 230KB; 1600 x 1075 pixels
