Photo #: S-584-153

Preliminary Design Plan for a "Small Battleship" ... April 23, 1919


Preliminary design plan for a "Small Battleship" (C-5). The Chief of the Bureau of Construction and Repair requested on 8 March 1919 that his staff develop a set of comparative studies for ships of this type, apparently reflecting his desire to anticipate a possible early need for retrenchment from the large capital ship designs under development at the time. The "C" series Small Battleship designs, initiated on 17 March, incorporated the four 16-inch gun armament and 12 inch side armor specified as an initial baseline for the type but had a further increased speed of 26 knots. The concept was not pursued.
This plan provided four 16-inch guns, electric drive machinery, and a speed of 26 knots in a ship 650 feet long on the waterline, 95 feet in beam, and with a normal displacement of 33,400 tons.
Note: The original document was a blueprint (white on dark blue).

The original plan is in the 1911-1925 "Spring Styles Book".

U.S. Naval Historical Center Photograph.

Online Image: 359KB; 2500 x 1095 pixels
