Photo #: 80-G-105489

Camouflage Measure 32, Design 6D


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for USS Holland (AS-3).
This plan, showing the ship's starboard side, superstructure ends and exposed decks, was prepared circa January-March 1944, and was approved by Captain Logan McKee, USN.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 116KB; 1200 x 645 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
