Photo #: 80-G-105500

Camouflage Measure 32, Design 11A


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for light cruisers of the CL-55 (Cleveland) class.
Ships known to have worn this scheme included USS Montpelier (CL-57) and USS Duluth (CL-87).
This plan, showing the ship's port side, is dated 27 January 1944, and was approved by Captain Logan McKee, USN.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 99KB; 1200 x 585 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
