Photo #: 80-G-109712

Camouflage Measure 33, Design 3D


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for escort aircraft carriers of the CVE-55 (Casablanca) class.
This plan, showing the ship's port side, is dated 13 April 1944 and was approved by Captain Torvald A. Solberg, USN.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 84KB; 1200 x 730 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
