Photo #: 80-G-109720

Camouflage Measure 32, Design 2C


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for USS St. Louis (CL-49). She was painted in this pattern during much of 1944.
This plan, showing the ship's starboard side, stern, superstructure ends, and exposed decks, is dated 31 March 1944 and was approved by Captain Torvald A. Solberg, USN.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 100KB; 1200 x 630 pixels
