Photo #: 80-G-109727

Camouflage Measure 32, Design 14D


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for heavy cruisers of the CA-24 (Pensacola) class.
USS Pensacola (CA-24) and USS Salt Lake City (CA-25) both wore this pattern.
This plan, showing the ship's port side, is dated 7 April 1944 and was approved by Captain Torvald A. Solberg, USN.

Official U.S. Navy Photograph, now in the collections of the National Archives.
