Photo #: 80-G-109731

Camouflage Measure 32, Design 7C


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for large cruisers of the CB-1 (Alaska) class.
USS Guam (CB-2) wore this pattern.
This plan, showing the ship's starboard side, superstructure ends, and exposed decks, is dated 7 April 1944 and was approved by Captain Torvald A. Solberg, USN.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 152KB; 2000 x 830 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
