Photo #: 80-G-152120
Camouflage Measure 33, Design 6T
Drawing prepared circa 1943-1944 by the Bureau of Ships for a camouflage scheme intended for attack transports of the APA-18 (President Jackson) class.
This plan shows the ship's starboard side, bow, stern and superstructure ends.
Official U.S. Navy Photograph, now in the collections of the National Archives.
