Photo #: 80-G-152121

Camouflage Measure 33, Design 6T


Drawing prepared circa 1943-1944 by the Bureau of Ships for a camouflage scheme intended for attack transports of the APA-18 (President Jackson) class.
This plan shows the ship's port side, bow, stern and some superstructure ends.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 102KB; 1200 x 710 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.



Click on the small photograph to prompt a larger view of the same image.

If you want higher resolution reproductions than this digital image, see: "How to Obtain Photographic Reproductions."
