Photo #: 80-G-156815

Camouflage Measure 32v11, Design 18D


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for destroyers of the DD-445 (Fletcher) class. It is marked "Approved by EW 8-19-43"
This plan shows the ship's starboard side, stern, superstructure ends and exposed decks.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 104KB; 1200 x 540 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
