Photo #: 80-G-157051

Camouflage Measure 33v13, Design 21D


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for the light cruiser Nashville (CL-43).
This plan shows the ship's starboard side, stern, superstructure ends, and exposed decks. It is marked "Approved by: EW 7/14/43"

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 127KB; 1200 x 590 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
