Photo #: 80-G-157052 Camouflage Measure 32v1, Design 1D Drawing prepared by the Bureau of Ships for a camouflage scheme intended for light cruisers of the Cleveland (CL-55) class, circa 1943. This pattern was applied to USS Houston (CL-81) and USS Miami (CL-89). Modified to use the lighter tones of Measure 33, it was also applied, at least on the port side, to USS Columbia (CL-56). This plan shows the ship's port side, stern, superstructure ends, and exposed decks. Official U.S. Navy Photograph, now in the collections of the National Archives. Online Image: 104KB; 1200 x 595 pixels Reproductions of this image may also be available through the National Archives photographic reproduction system. |
![]() |
