Photo #: 80-G-160236
Camouflage Measure 32, Design 3AO
Drawing prepared by the Bureau of Ships, circa 1943, for a camouflage scheme intended for oilers of the Ashtabula (AO-51) class.
This plan shows the ship's port side and superstructure ends.
Official U.S. Navy Photograph, now in the collections of the National Archives.
