Photo #: 80-G-162021

Camouflage Measure 31, Design 7L


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for Landing Craft, Tank [LCT].
This plan, dated 17 December 1943, shows the ship's starboard side, bow, stern and exposed decks. It was approved by Captain Henry A. Ingram, USN.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 111KB; 1200 x 595 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
