Photo #: 80-G-165988

Camouflage Measure 32, Design 5AO


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for oilers of the AO 22-32 and 51-64 class. It could also be "adapted to the AO 66-72 class and other vessels of similar construction".
This plan, approved by Captain Logan McKee, USN, is dated 21 February 1944. It shows the ship's port side and also specifies a color scheme for embarked motor torpedo boats (PT).

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 156KB; 1200 x 645 pixels
