Photo #: 80-G-170021

Camouflage Measure 32, Design 13D


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for heavy cruisers of the CA-32 (New Orleans) class.
This plan, approved by Captain Logan McKee, USN, was probably prepared about 3 February 1944. It shows the ship's port side.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 146KB; 1500 x 815 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
