Photo #: 80-G-170030
Camouflage Measure 31, Design 9L
Drawing prepared by the Bureau of Ships for a camouflage scheme intended for dock landing ships of the LSD-1 (Ashland) class.
This plan, approved by Captain Henry A. Ingram, USN, is dated 12 January 1944. It shows the ship's starboard side, the port interior side of the well deck, stern, superstructure ends, and exposed decks.
Official U.S. Navy Photograph, now in the collections of the National Archives.
Online Image: 135KB; 1200 x 595 pixels
Reproductions of this image may also be available through the National Archives photographic reproduction system.
Click on the small photograph to prompt a larger view of the same image.
If you want higher resolution reproductions than this digital image, see: "How to Obtain Photographic Reproductions."
Image posted 8 November 2005
