Photo #: 80-G-172530

Camouflage Measure 33, Design 6Ao


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for cargo ships of the AK-156 (Alamosa) class.
This plan, approved by Captain Torvald A. Solberg, USN, is dated 10 May 1944. It shows the ship's starboard side and superstructure ends.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 123KB; 1200 x 770 pixels
