Photo #: 80-G-172862
Camouflage Measure 32, Design 8F
Drawing prepared by the Bureau of Ships for a camouflage scheme intended for amphibious force flagships of the AGC 1-3, 5 and 7-14 (Appalachian) class. The design could be adapted to vessels of similar construction.
This plan, approved by Commander William C. Latrobe, USN, is dated 20 March 1944. It shows the ship's starboard side and superstructure ends.
Official U.S. Navy Photograph, now in the collections of the National Archives.
Online Image: 186KB; 1200 x 880 pixels
Reproductions of this image may also be available through the National Archives photographic reproduction system.
Click on the small photograph to prompt a larger view of the same image.
If you want higher resolution reproductions than this digital image, see: "How to Obtain Photographic Reproductions."
Image posted 24 December 2005
