Photo #: 80-G-172875
Camouflage Measure 32, Design 8F
Drawing prepared by the Bureau of Ships for a camouflage scheme intended for amphibious force flagships of the AGC 1-3, 5 and 7-14 (Appalachian) class. The design could be adapted to vessels of similar construction.
This plan, approved by Commander William C. Latrobe, USN, is dated 20 March 1944. It shows the ship's port side.
Official U.S. Navy Photograph, now in the collections of the National Archives.
