Photo #: 80-G-172885

Camouflage Measure 31, Design 3D


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for destroyers of the DD-423 (Gleaves) class.
This plan, approved by Captain Torvald A. Solberg, USN, is dated 5 June 1944. It shows the ship's starboard side, superstructure ends, and exposed decks.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 122KB; 1200 x 630 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
