Photo #: 80-G-172986

Camouflage Measure 31, Design 11L


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for tank landing ships of the LST-1, LST-491 and LST-542 classes.
This plan, approved by Captain Torvald A. Solberg, USN, is dated 22 May 1944. It shows the ship's port side.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 114KB; 1200 x 805 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
