Photo #: 80-G-173258

Camouflage Measure 32, Design 4AO


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for oilers of the AO-2 (Maumee) class.
This plan, approved by Captain Logan McKee, USN, is dated 16 February 1944. It shows the ship's port side.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 117KB; 1200 x 605 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
