Photo #: 80-G-173483

Camouflage Measure 33, Design 11T


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for transports of the AP-130 (Maritime Commission type C4-S-A1) class.
This plan, approved by Captain Torvald A. Solberg, USN, is dated 13 April 1944. It shows the ship's port side.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 136KB; 1200 x 800 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
