Photo #: 80-G-174546

Camouflage Measure 32, Design 8AO


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for gasoline tankers of the AOG-17 (Mettawee) class.
This plan, approved by Captain Torvald A. Solberg, USN, is dated 4 May 1944. It shows the ship's starboard side and superstructure ends.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 141KB; 1200 x 840 pixels
