Photo #: 80-G-174764
Camouflage Measure 32, Design 10Ax
Drawing prepared by the Bureau of Ships for a camouflage scheme intended for submarine tenders of the AS-13 (Griffin) class.
This plan, approved by Captain Torvald A. Solberg, USN, is dated 28 April 1944. It shows the ship's port side.
Official U.S. Navy Photograph, now in the collections of the National Archives.
Online Image: 69KB; 1200 x 660 pixels
Reproductions of this image may also be available through the National Archives photographic reproduction system.
Click on the small photograph to prompt a larger view of the same image.
If you want higher resolution reproductions than this digital image, see: "How to Obtain Photographic Reproductions."
Image posted 9 March 2006
