Photo #: 80-G-174772

Camouflage Measure 33, Design 4Ab


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for USS Enterprise (CV-6).
This plan, approved by Captain Logan McKee, USN, is dated 23 February 1944. It shows both of the ship's sides, her stern and her superstructure ends.
Enterprise was painted in this camouflage pattern later in 1944.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 311KB; 2000 x 1160 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
