Photo #: 80-G-176516
Camouflage Measure 33, Design 8C
Drawing prepared by the Bureau of Ships for a camouflage scheme intended for light cruisers of the CL-40 (Brooklyn) class.
This plan, approved by Captain Torvald A. Solberg, USN, appears to be dated 28 July 1944. It shows the ship's starboard side, exposed decks, and superstructure ends.
Official U.S. Navy Photograph, now in the collections of the National Archives.
Online Image: 107KB; 1200 x 575 pixels
Reproductions of this image may also be available through the National Archives photographic reproduction system.
Click on the small photograph to prompt a larger view of the same image.
If you want higher resolution reproductions than this digital image, see: "How to Obtain Photographic Reproductions."
Image posted 21 May 2006
