Photo #: 80-G-176518

Camouflage Measure 32, Design 4T


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for attack transports of the APA-117 (Haskill) class. It is mislabled in the plan's data box as representing the APA-110 (Griggs) class, which had a different appearance.
This plan, approved by Commander Arthur W. Colledge, USNR, appears to be dated 1 August 1944. It shows the ship's starboard side and superstructure ends.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 104KB; 1200 x 760 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
