Photo #: 80-G-176519

Camouflage Measure 31, Design 17L


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for landing ships medium of the LSM-1 class.
This plan, approved by Captain Torvald A. Solberg, USN, appears to be dated 13 July 1944. It shows the ship's port side, and the interior of the starboard side of the tank well deck.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 160KB; 1200 x 570 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
