Photo #: 80-G-176520

Camouflage Measure 31, Design 17L


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for landing ships medium of the LSM-1 class.
This plan, approved by Captain Torvald A. Solberg, USN, appears to be dated 13 July 1944. It shows the ship's starboard side, stern, exposed decks, superstructure ends, interior of the port side and stern bulkhead of the tank well deck, and gives details on how the pattern edges should be applied.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 151KB; 1200 x 560 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
