Photo #: 80-G-177468
Camouflage Measure 31, Design 20-L
Drawing prepared by the Bureau of Ships for a camouflage scheme intended for high-speed transports of the APD-1 (Manley) class.
This plan, approved by Commander Wallace S. Newton, USN, is dated 18 August 1944. It shows the ship's port side.
Official U.S. Navy Photograph, now in the collections of the National Archives.
