Photo #: 80-G-703025

"Typical Aircraft Carrier"


Right half of a cut-away profile drawing prepared by the Bureau of Ships, 7 November 1942. Ship shown represents USS Yorktown (CV-5) and USS Enterprise (CV-6), combining features of the ship's peacetime and early wartime configurations.
The left half of this drawing is Photo # 80-G-703026.

Official U.S. Navy Photograph, now in the collections of the National Archives.

Online Image: 77KB; 740 x 435 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
